Description
The Portable Conductivity/DO Meter YR06382 is a state-of-the-art device designed for accurate measurement of conductivity and dissolved oxygen in various environments. Featuring a large LCD screen with adjustable white backlight, this portable meter is equipped with a built-in microprocessor chip that provides intelligent functions such as auto calibration, automatic temperature compensation (ATC), data storage, and self-diagnosis, ensuring reliability and ease of use. With advanced conductivity measurement technology and a robust polarographic DO electrode, this meter is ideal for professionals in laboratory and field settings seeking precision and efficiency.
Market Price Overview
The average market price for advanced portable conductivity and dissolved oxygen meters ranges widely, typically between $700 USD and $1100 USD. Factors influencing this range include device features, brand reputation, and additional functionality. The YR06382 model offers a competitive and attractive option within this range, providing excellent value with its comprehensive capabilities.
Frequently Asked Questions
- How portable is the YR06382 Meter? This meter is highly portable with dimensions of 65×120×31mm and a lightweight design, perfect for on-the-go measurements.
- What kind of batteries does it use? The device operates using two standard AA batteries, ensuring ease of replacement and longer operational life.
- Can the YR06382 be used in both freshwater and saltwater environments? Yes, it is suitable for both types of water due to its versatile range of conductivity and salinity measurements.
Advantages and Disadvantages
- Advantages: Offers auto calibration, large LCD display for easy reading, comprehensive measurement ranges, and robust data storage capabilities.
- Disadvantages: Requires manual pressure compensation for DO measurements, which may be less convenient for some users.
Product Use in the Field
In practice, the YR06382 Meter is commonly employed in various environments such as laboratories, environmental monitoring tasks, and industrial settings. Its reliable performance and quick response time make it an essential tool for professionals needing accurate readings of water quality parameters.
Recommendations
For optimal performance, it is recommended to regularly calibrate the device as per provided guidelines and ensure electrodes are maintained clean. Utilizing compatible calibration solutions will also help preserve accuracy. Consider exploring the Kalstein Plus platform to request a quote or a personalized proposal for your specific needs.
Features
- Large LCD display with controllable backlight
- Intelligent microprocessor functions including ATC, data storage, and auto calibration
- Advanced conductivity measurement technology
- Short polarization time for DO measurements
- Versatile range for conductivity, TDS, salinity, and resistivity measurements
Technical Specifications
| Model | YR06382 | |
|
Cond.
|
Measuring range
|
Conductivity: |
| (0.00~19.99)μS/cm | ||
| (20.0~199.9)μS/cm | ||
| (200~1999)S/cm | ||
| (2.00~19.99)mS/cm | ||
| (20.0~199.9)mS/cm | ||
| TDS:(0~100)g/L | ||
| Salinity:(0~100)ppt | ||
| Resistivity:(0~100)MΩ·cm | ||
| Resolution | 0.01/0.1/1μS/cm; 0.01/0.1 mS/cm | |
| Accuracy | ±1.0% FS, Overall:±1.5% FS | |
| Temp. compensation | (0~100)ºC(Auto/manual) | |
| Electrode constant | 0.1 / 1 / 10 cm-1 | |
|
DO
|
Measuring range | (0 ~ 20.00) mg/L(ppm), (0 ~ 200.0)% |
| Resolution | 0.1/0.01 mg/L(ppm), 1/0.1 % | |
| Accuracy | Electrode: ±0.10 mg/L, Instrument: ±0.40 mg/L | |
| Response time | ≤30s (25ºC, 90%response) | |
| Residual current | ≤0.1 mg/L | |
| Temp. compensation | (0 ~ 45)ºC (auto) | |
| Salinity compensation | (0 ~ 45) ppt (auto) | |
| Pressure compensation | (66 ~ 200) kPa (manual) | |
| Auto calibration | Air saturated by water, water saturated by air | |
| Electrode type | Polarographic | |
|
Temp.
|
Measuring range | (0 ~ 100)ºC |
| Resolution | 0.1ºC | |
| Accuracy | 5 ~ 60ºC:±0.4ºC Others: ±0.8ºC | |
|
Other
|
Data storage | 200 sets |
| Power | Two AA batteries (1.5V x2) | |
| Ambient Temp. | 5 ~ 35 ºC | |
| Ambient humidity | ≤85% | |
| IP grade | IP57 Dustproof and waterproof | |
| Dimensions/N.W. | (65×120×31)mm/180g | |
| Shipping size/G.W. | (460×300×55)mm/1Kg | |
