Description
The Benchtop Conductivity/DO Meter YR06384 is an advanced measurement tool designed to deliver precise readings for conductivity and dissolved oxygen. It features a vibrant 7-inch capacitive touch screen, ensuring a user-friendly interface with high resolution and sensitivity. Equipped with a built-in microprocessor, this meter provides intelligent functions such as automatic calibration, automatic temperature compensation, data storage, and wireless communication. It supports seamless data transfer via USB, Bluetooth, and allows for efficient wireless printing. Perfectly suited for laboratories, it offers smart electrode status displays, ensuring consistent accuracy for professional use.
Price in the Market
The Benchtop Conductivity/DO Meter YR06384 stands out for its robust capabilities in precision measuring equipment. This type of equipment generally ranges between $1,200 to $2,000 in the current market, reflecting the sophistication and technological advantages it offers. Investing in a reliable meter like this ensures the utmost accuracy and efficiency in your workflow.
Frequently Asked Questions
Q: Can I connect the meter to a computer?
A: Yes, it supports PC connection via USB or Bluetooth for data transfer.
Q: How much data can it store?
A: The meter can store up to 1000 sets of test data.
Q: Is there an automatic calibration feature?
A: Yes, the device offers automatic calibration to ensure measurement precision.
Advantages and Disadvantages
Advantages:
- High-resolution touch screen for ease of use
- Intelligent features with automatic calibration
- Bluetooth and USB connectivity for versatile data management
- Large storage capacity for data logging
Disadvantages:
- Initial setup might require comprehensive calibration to match specific needs.
- Higher price point compared to simpler models.
Product Use in the Field
The Benchtop Conductivity/DO Meter YR06384 is primarily used in laboratory environments but is also applicable in field studies requiring precise conductivity and DO measurements. Its capability to switch among conductivity, TDS, salinity, and resistivity measurements makes it a versatile tool for environmental and industrial applications.
Recommendations
To maximize the performance and longevity of the Benchtop Conductivity/DO Meter YR06384, it’s recommended to perform regular calibration checks, utilize the Bluetooth feature for real-time data monitoring, and protect the device by ensuring that it is used within the specified ambient conditions. For purchasing, consider reaching out to our platform, Kalstein Plus, for a detailed quote today.
Features
- Colorful 7-inch capacitive touch screen
- Automatic temperature compensation
- 1000 data sets storage with easy export
- Switchable modes: Conductivity, TDS, salinity, resistivity
- Wireless printing and Bluetooth connectivity
Technical Specifications
| Model | YR06384 | |
|
Cond.
|
Measuring range
|
Conductivity: |
| (0.00~20.00)μS/cm, (20.0~200.0)μS/cm | ||
| (200~2000)μS/cm, (2.00~20.00)mS/cm | ||
| (20.0~200.0)mS/cm, | ||
| (200~2000)mS/cm (K=10) | ||
| TDS:(0 ~ 100)g/L | ||
| Salinity:(0 ~ 100)ppt | ||
| Resistivity:(0 ~ 100)MΩ·cm | ||
| Resolution | 0.01/0.1/1μS/cm; 0.01/0.1mS/cm | |
| Accuracy | Electrode: ±0.5% FS, Meter: ±0.8% FS | |
| Temp. compensation range | (0 ~ 50)ºC, auto | |
| Electrode constant | 0.1/0.5/1/5/10/50/100 cm-1 | |
| Reference Temp. | 25ºC,20ºC,18ºC | |
|
DO
|
Measuring range | (0 ~ 20.00)mg/L(ppm) (0 ~ 200.0)% |
| Resolution | 0.1/0.01 mg/L(ppm) 1/0.1 % | |
| Accuracy | Electrode: ±0.10 mg/L, Meter: ±0.40 mg/L | |
| Response time | ≤30s (25ºC, 90%response) | |
| Residual current | ≤0.1 mg/L | |
| Temp compensation | (0 ~ 45)ºC, auto | |
| Salinity compensation | (0 ~ 45) ppt, auto | |
| Pressure compensation | (80 ~ 105) kPa, auto | |
| Auto calibration | Air saturated by water; water saturated by air | |
| Electrode type | Polarographic | |
|
Temp.
|
Range | (-10 ~ 110)ºC |
| Resolution | 0.1ºC | |
| Accuracy | 5 ~ 60ºC:±0.4ºC Others: ±0.8ºC | |
|
Other
|
Display | 7-inch colored capacitive touch screen |
| Data storage | 1000 sets | |
| Power | 12V/1A | |
| Output | USB, RS232, Bluetooth | |
| Ambient Temp. | 15 ~ 30 ºC | |
| Ambient Humidity | ≤85% | |
| IP grade | IP54 | |
| Dimensions/N.W. | 240×170×70mm/600g | |
| Shipping Size/G.W. | 470x430x85mm/2.6kg | |
