Technical Glossary and Key Terminology for the YR05889 Heated Lid Dry Bath Incubator
The YR05889 Heated Lid Dry Bath Incubator is a sophisticated piece of laboratory equipment designed for precise temperature control during sample incubation. Understanding the technical terminology associated with this model is crucial for effective operation and optimal results. This article serves as a technical glossary, defining key terms that are vital for users of the YR05889.
Introduction to the YR05889 Heated Lid Dry Bath Incubator
The YR05889 is engineered for various applications, including DNA amplification, protein denaturation, and sample preservation. Its heated lid feature ensures even temperature distribution, while advanced semiconductor technology (Peltier-based) provides rapid heating and cooling.
Technical Specifications of the YR05889
| Model | YR05889 |
|---|---|
| Voltage | AC100~240V, 50/60Hz |
| Temperature Adjustment Range for Block | R.T. -25℃ ~100℃ |
| Temperature Adjustment Range for Lid | R.T. +5℃ ~110℃ |
| Timer | 1 s~99 min 59 s (0 means infinite) |
| Temperature Accuracy for Block | ±0.5℃ |
| Temperature Accuracy for Lid | ±1.0℃ |
| Temperature Uniformity for Block | ±0.5℃ |
| Display Accuracy | 0.1℃ |
| Heating Rate (R.T. 25 ℃) | 37℃ -100℃ ≥ 7℃ /min |
| Cooling Rate | 100℃ -37℃≤ 8℃ /min |
| Max Steps | 10 |
| Max Cycles | 99 |
| Max Power | 200W |
Glossary of Key Terms
| Term | Definition |
|---|---|
| Peltier Technology | A thermoelectric technology used for heating and cooling, vital for the functionality of the YR05889. |
| Temperature Uniformity | Refers to how consistently the temperature is maintained across the incubation block. |
| Heating Rate | The speed at which the incubator reaches the desired temperature. |
| Cooling Rate | The speed at which the incubator can lower temperature after heating. |
| Incubation | The process of maintaining controlled conditions for biological samples. |
| Microcontroller | A compact integrated circuit designed to govern specific operations of the incubator. |
| Cycle | A complete sequence of heating and cooling processes used in sample treatment. |
| Timer | A function that allows users to set specific durations for incubation. |
| Display Accuracy | The precision of the temperature readings shown on the incubator's interface. |
| Sample Preservation | Maintaining the integrity of biological samples through controlled conditions. |
Frequently Asked Questions
What is the importance of temperature uniformity in the YR05889?
Temperature uniformity is critical in ensuring consistent results during sample incubation. Variability in temperature can lead to inaccurate experimental outcomes, affecting the integrity of the samples.
How does the Peltier technology work in the YR05889?
Peltier technology operates by transferring heat from one side of the device to another, allowing precise temperature control for both heating and cooling functions in the incubator.
What applications can the YR05889 be used for?
The YR05889 is suitable for a variety of applications, including DNA amplification, protein denaturation, and maintaining optimal conditions for sample preservation.
What maintenance does the YR05889 require to ensure optimal performance?
Regular cleaning, calibration of temperature settings, and periodic inspection of the internal components are essential for maintaining the YR05889's performance.
Can the YR05889 accommodate different sample types?
Yes, the YR05889 can accommodate various sample types, including microtubes and PCR plates, depending on the specific operational settings utilized.
Conclusion
Understanding the technical terminology related to the YR05889 Heated Lid Dry Bath Incubator enhances the ability to operate this advanced equipment effectively. Knowledge of key terms ensures that users can maximize the capabilities of the incubator for their specific applications.
