Description
‘-86℃ Ultra low temperature Chest freezer for Lab/Hospital 105L
Characteristic Function
- Safety door lock design to prevent abnormal door open
- Wide voltage for AC187V-242V
- Mute design for silent needed environment
- Digital display with big screen, easy to check
- Excellent thermal insulation performance with silicone door seal design(second door seal optional)
- Mobile and fixable weel for move
Safety Guarantee
- Temperature H/L alarm, sensor malfunction alarm, thermostat failure alarm
- Audible and visible alarm
- Keyboard lockable, password protection to prevent change running parameter randomly
- Display running parameter with real-time monitoring to guarantee the stability of freezer
Refrigeration System
- Imported brand compressor work with CFC-Free environmental rerigerant
- High desity insulation foam layer with better heat preservation effect
- Optimized self-cascade refrigeration system to provide faster cooling speed with lower power consumption
Temperature ControlMode
- With the international famous brand computer temperature control system to keep the inner temperature accurate and stable. Temperature adjusted from -40ºC to -86ºC.
- High light digital display
- H/L temperature alarm, the alarm temperature can be set as needed
- PTC tempearture sensor, to make sure temperature accurately
Technical Specifications
| Model | YR05313 | |
| Specificaitons | Shelf/drawer QTY | / |
| Cooling | Direct cooling | |
| Defrost | Manual | |
| Refrigerant | Mixed-gas | |
| Power Consumption(kWh/24h) | 3.8 | |
| Noise(db) | 50 | |
| Ambient temperature(℃) | 10~32℃ | |
| Temperature range(℃) | -40~-86℃ | |
| Cooling system | Compressor brand/QTY | CUBIGEL/1 |
| Sensor | PTC | |
| Temperature controller | Microprocessor | |
| Display | Digital display | |
| Power | Voltage/frequency(V/Hz) | 220/50Hz |
| Power(W) | 500W | |
| Current(A) | 2.9 | |
| Material | Inside material | Stainless steel |
| Outside material | Color sprayed steel | |
| Insulation | PURF | |
| Size | Capacity(L/cu.ft) | 105/3.70 |
| NT./GT.(kg) | 63.7/68.5 | |
| Exterior size(W*D*H)(mm) | 680*580*935 | |
| Interior size(W*D*H)(mm) | 480*380*665 | |
| Package size(W*D*H)(mm) | 770*705*1090 | |
| CBM | 0.59 | |
| 20GP/40GP/40HQ | 24/51/51 | |
| Frozen Racks | Racks | 4(11X1,6X1) |
| Boxes (2 Inches) | 34 | |
| Samples(2ml) | 3400 | |
| Alarm | High/low temperature | Y |
| Power failure | / | |
| Abnormal voltage | / | |
| Sensor error | Y | |
| Filter screen check | / | |
| Thermostat failure | Y | |
| Low battery | / | |
| Condenser clean | / | |
| High ambient temperature | / | |
| Door ajar | / | |
| Power failure backup system(alarm) | 12h | |
| Accessories | Castor | Y |
| Inside door | / | |
| Test hole QTY/diameter | 1/25MM | |
| USB port | / | |
| Chart recorder | / | |
| Data logger | Optional | |
| Remote alarm port | / | |
| Optional | CO2 back up system | Optional |
| LN2 back up system | Optional | |
| Other | Certification | ISO.CE |
